SWACO Shaker Screen

Mongoose/Meerkat Shale Shaker Screen
Steel frame replacement screens for the Mongoose PT and Meerkat PT shale shaker combine proven mesh combinations with an innovative, square-patterned plate to improve separation efficiency of the shaker, while extending screen life.

New designed composite screens are the most rugged, long lasting and efficient screens, provide resistance to corrosive drilling fluids. The screens also offer significant fluid capacity, large screening area achieved.

Composite construction creates an ultra tight seal between the screen and the screen deck, eliminates solids buildup and costly solids bypass. The unique screen locking mechanism wedges the screen firmly in place and allows the screen to be removed for repair or replacement.

Shaker Model	Screen Type	API  RP 13C Non Blanked Screen Area
Mongoose/Meerkat	Composite	5.3 sq.ft.
Mongoose/Meerkat	Steel Frame	4.5 sq.ft

MD-2 & MD-3 Shale Shaker Screen
Composite screen technology increases effective open area, improves process capacity, and maximizes screen life. Pre-tensioned screens allow for more efficient screen changes

Shaker Model	Screen Type	API  RP 13C Non Blanked Screen Area
MD-2 & MD-3	Composite	2.6 sq.ft.

BEM600/650 Shale Shaker Screen
Metal supported screen panel configured with prestensioned wire cloth improves the fluid process capacity, and save the screen replacement time.

Shaker Model	Screen Type	API  RP 13C Non Blanked Screen Area
BEM600/650	Steel Frame	4.8sq.ft.

ASL-II Shale Shaker Screen
Hookstrip flat screens are the series applied most widely at present. This screen can be fit on ALS-II shale shakers. The screen panel is constructed with two or three stainless steel layers bonded to a metal support panel.

Shaker Model	Screen Type	API  RP 13C Non Blanked Screen Area
ASL-II	Hookstrip	10.6 sq.ft.
